Landsat and America’s Water Resources
Published on by Water Network Research, Official research team of The Water Network in Technology
As droughts rage and aquifers dwindle, people may wonder: Is there enough water to meet all our needs? Landsat satellites are helping to answer that question.
Water Use Mapping
Using Landsat satellite data, scientists with the U.S. Geological Survey (USGS) have helped to refine a technique called evapotranspiration (ET) water-use mapping to measure how much water crops are using across landscapes and through time. These ET water-use maps are created using a computer model that integrates Landsat and weather data.
This pair of ET water-use maps shows crop water use in California’s San Joaquin Valley in 1990 (left) and 2014 (right). Comparing the maps reveals changes in irrigation patterns during this period. Notice, for example, that water use intensified in many places (increase in blue areas) and some irrigated lands (green in 1990) transitioned out of agricultural production (reddish brown) by 2014.
Crucial to the process is Landsat’s thermal (infrared) band. Thanks to that thermal band with its 100-meter resolution, water-use maps can be created at a scale detailed enough to show how much water crops are using at the level of individual fields anywhere in the country.
From Daily Glimpses to Long-term Trends
ET water-use maps can show how much water crops are using in a single day or during an entire growing season. Drawing on the vast Landsat satellite image archive, it’s also possible to create maps that span decades to reveal long-term trends in water use (top). That Landsat archive—invaluable to water-use mapping and so much more—might never have become a reality without the visionary support given to Earth observation from space by Interior Secretary Stewart Udall during the 1960s.
How Water-Use Maps Help
USGS scientists can map water use at different scales to address different water resource questions and concerns. Field-scale maps, for example, are powerful tools for estimating and managing water consumption on irrigated croplands. They can help answer questions such as:
- Where is water being used, how much, and by whom?
- Which types of crops are using the most, or least, water?
- Can water be used more efficiently without impacting crop yields?
Basin-scale water-use maps assist in understanding water balance and availability in river basins and watersheds. These large-area maps are useful for:
- Estimating water use by different sectors within a watershed.
- Resolving disputes regarding water rights and allocations.
- Evaluating aquifer depletions and quantifying net ground water pumping.
Planning Today for Water Tomorrow
According to a recent Government Accountability Office report, 40 of 50 state water managers expect water shortages in their states between now and 2023. Addressing concerns about America’s water resources begins with a clearer understanding of water availability and water-use trends. Mapping water use based on Landsat satellite data has demonstrated immense potential at local and regional scales, and will soon become the basis for monitoring and assessing water use across the nation.
Source: USGS
