Manganese Oxides in Treatment System Could Be Mixed Blessing

In a “bad news, good news” scenario, researchers at North Carolina State University have found that some black sludge growing in a water-treatment site could have redeeming benefits.

The black sludge coated water pump components at a superfund site in Raleigh. Generally, the presence of such material gums up the water-treatment site’s primary task of cleaning fouled water, says Owen Duckworth, an NC State associate professor of soil science and the corresponding author of a paper describing a study on the black sludge and its characteristics.

Black sludge at a water-treatment site is mostly something to be avoided rather than encouraged, he said.

But as the researchers used powerful microscopic and X-ray techniques to closely examine the sludge, they found that it contained manganese oxides.

“Manganese oxides have low toxicity and are of technological interest because they suck up metals and cause chemical reactions that chew up organic matter,” Duckworth said. “So they’re used in things like water treatment to get micro-pollutants out of water.”

The manganese oxides at the water-treatment site are small but have large affinities for metal. They are thousands of times smaller than the width of a human hair, and shaped like dinner plates with holes in the middle.

“Metals like zinc, copper and lead, for example, will sit in the holes of the plates or stick to the edges,” Duckworth said. “And, the naturally occurring manganese oxides have more holes than those grown in a lab setting, making them even more effective in sucking up metals.”

During their testing, the researchers found that manganese was oxidized by a fungal catalyst.

“Unlike iron, which oxidizes when exposed to air, manganese needs a catalyst to oxidize,” Duckworth said. “In this case, we found evidence of a fungal catalyst.”

Moreover, the researchers found that the manganese oxides in the water-treatment plant, which appeared to grow naturally, are similar to what scientists would grow in a lab setting to test the oxides’ utility in environmental remediation.

The research was supported by the National Science Foundation Environmental Chemical Sciences Program (award CHE-1407180) and the U.S. Department of Energy, Office of Science, Office of Basic Energy Sciences under contract No. DE-AC02-76SF00515. Researchers from NC State and the University of Minnesota co-authored the paper, which is published in  Environmental Science: Process & Impacts .

– kulikowski –

Note : An abstract of the paper follows.

“Morphology, Structure, and Metal Binding Mechanisms of Biogenic Manganese Oxides in a Superfund Site Treatment System”

Authors : O.W. Duckworth, N.A. Rivera, T.G. Gardner, M.Y. Andrews and M.L. Polizzotto, North Carolina State University; C.M. Santelli, University of Minnesota

Published : Online Dec. 1, 2016, in  Environmental Science: Process & Impacts

DOI : 10.1039/c6em00525j

Abstract :

Manganese oxides, which may be biogenically produced in both pristine and contaminated environments, have a large affinity for many trace metals. In this study, water and Mn oxide-bearing biofilm samples were collected from the components of a pump and treat remediation system at a superfund site. To better understand the factors leading to their formation and their effects on potentially toxic metal fate, we conducted a chemical, microscopic, and spectroscopic characterization of these biofilm samples. Scanning electron microscopy revealed the presence of Mn oxides in close association with biological structures with morphologies consistent with fungi. X-ray absorption spectroscopy (XAS) and X-ray diffraction (XRD) revealed the oxides to be a mixture of layer and tunnel structure Mn (IV) oxides. In addition, XAS suggested that Ba, Co, and Zn all primarily bind to oxides in the biofilm in a manner that is analogous to synthetic or laboratory grown bacteriogenic Mn oxides. The results indicate that Mn oxides produced by organisms in the system may effectively scavenge metals, thus highlighting the potential utility of these organisms in designed remediation systems.
