MechE Students Design First Water Barrel that Filters as you Roll

For those who live in regions where water pours from tubes in their homes, it might be difficult to imagine that there are still people on Earth without access to clean water.

For these people, clean water is often miles away from their homes. They are forced to walk for hours, carrying full baskets of water, only to spend a few more hours filtering that water before it is safe for their families to drink. Researchers around the world are working hard on developing devices to make transportation easier, and ones to make purification quicker.

But what about a single device that could do both?

“We had already seen some ideas out there that filtered water, and others that rolled the water using barrels, but we wanted to create something that filtered while you rolled,” explains Mechanical Engineering senior Deepak Ravi. “Something better than doing the two of them separately.”

Ravi and fellow MechE seniors Anna Mirabella, Jack Kaplan, Veronica Jamie-Lara, and Alex Baker put their heads together and designed the Water Transportation and Purification System.

“The design is basically a big barrel with a smaller barrel inside of it, attached to a handle,” says Mirabella. “As you roll the barrel along, the relative motion between the handle and the spinning barrel pulls dirty water from the outer barrel through a filter and into the inner barrel where it stores the newly cleaned water.”

The design uses only a few simple parts and requires no power, only mechanical energy provided by the rolling of the barrel. It uses a Sawyer water filter, which never needs to be replaced, and recycled industrial barrels—food-grade plastic barrels that are normally just thrown away. With PVC pipe for the handle, the whole prototype cost only about $200. When mass-produced, the team estimates the total cost at only $40 per unit.

“We’ve decided to make this design open source,” adds Mirabella. “If someone wants to manufacture our system and get it down to that $40, none of us would be upset. It would be awesome to have had a small part of something big.”

Another way this product will keep costs down for the user is its instantaneous filter. Since the water is already purified en route home, users can empty the clean water into a container, then hand the device off to their neighbor. That way, a single device can be shared among an entire community.

The team developed the idea as the final project for their Mechanical Engineering Senior Design course, taught by Associate Teaching Professor Noé Vargas Hernández. The class is required of all MechE majors for graduation and emphasizes the ability to take a project from conception to prototype over the course of a semester.

“This wasn’t just a mechanical engineering project for us,” Ravi says. “Some of us are also design minors, so we thought about how it would be filled, and how it would be made. We thought about the user. That’s why we went with a 15-gallon tank; 15 gallons is about a weekly supply of water for a family in the developing world.”

“I think that’s one of the best things about being able to work here at Carnegie Mellon,” he adds. “All of our different disciplines combine to make the best outcome.”

To learn more about how innovators across the globe are changing the world of water, check out #WorldWaterDay.
