Safeguards for Shallow Fracking's Effects on Drinking Water

Scientist's investigations show that drinking water sources may be threatened by thousands of shallow oil and gas wells mined with the controversial process of hydraulic fracturing. A new study suggests safeguards

Ongoing research by Stanford environmental scientist Rob Jackson attempts to minimize the risks of "fracking" to underground drinking water sources.

The most recent such study, published in Environmental Science & Technology , finds that at least 6,900 oil and gas wells in the U.S. were fracked less than a mile (5,280 feet) from the surface, and at least 2,600 wells were fracked at depths shallower than 3,000 feet, some as shallow as 100 feet. This occurs despite many reports that describe fracking as safe for drinking water only if it occurs at least thousands of feet to a mile underground, according to Jackson.

The authors also estimated water use for hydraulic fracturing in each state. The states with the highest average water use per well were Arkansas, Louisiana, West Virginia and Pennsylvania.

Perhaps most surprisingly, the researchers discovered that at least 2,350 wells less than one mile deep had been fracked using more than 1 million gallons of water each. Shallower high-volume hydraulic fracturing poses a greater potential threat to underground water sources because there is so little separation between the chemicals pumped underground and the drinking water above them.

"Shallow hydraulic fracturing is surprisingly common," said Jackson, the Michelle and Kevin Douglas Provostial Professor in the School of Earth, Energy & Environmental Sciences and a senior fellow at the Stanford Woods Institute for the Environment and the Precourt Institute for Energy. "The places where hydraulic fracturing is both shallow and water-intensive may need additional safeguards."

For example, Arkansas had more than 300 wells fracked shallower than 3,000 feet, using an average of 5 million gallons of water and chemicals. Other states that fracked wells shallower than 3,000 feet using more than a million gallons each included New Mexico (16), Texas (10), Pennsylvania (seven) and California (two).

Energy revolution

Jackson has tracked the dramatic transformation toward energy independence and the pressing questions swirling around fracking's impact on water supplies.

"There's a lot at stake economically," Jackson said. "My interest is in trying to make the process as safe as possible."

Although fracking in the U.S. produces more than 100 billion gallons of wastewater per year, the process requires significantly less water per unit of energy than extraction and processing for coal and nuclear power, according to past research by Jackson and his colleagues.

As part of the so-called frackwater they inject into the ground, drilling companies use proprietary blends of chemicals that can include hydrochloric acids, toluene and benzene. When the wastewater comes back up after use, it often includes those and potentially dangerous natural chemicals such as arsenic, selenium and radioactive radium drawn up from subterranean recesses.

Because oil and gas companies must drill tens of thousands of new wells each year in the United States to maintain production through time, groundwater contamination remains a possibility.

Source: Science Daily
