EXL: High Flow EDI for Power Generation, Industrial, and Pharmaceutical Water

EXL Pharmaceutical HTS 85C

EXL by Electropure™ product modules are designed to be the highest flow Electrodeionization modules on the market. EXL modules can handle flow rates up to 10 m3/hr (44 gpm) depending on the specific requirements of the customer. EXL was in limited release in China as of 2009.

EXL

• EXL Modules have permanent O-Ring seals on each chamber and require no torqueing
• Electropure™ EDI technology with the same physical profile as E-Cell® MK3 and Ionpure® LX modules.
• Includes SnowPure’s patented Excellion™ membranes
•  EXL feed and product ports options:
  1. +GF+ Unions 40DN32 1-1/4” for EXL-750,  850
  2. +GF+ Unions 32DN25 1”  for EXL-650
  3. DN40 1-1/2″ Sanitary Tri-Clamp® for EXL-510-HTS, 610-HTS, 710-HTS, 650, 750, 850
  4. MAXI 1″ Sanitary Tri-Clamp® (E-Cell® MK2 and MK3 replacement) for EXL-510-HTS, 610-HTS, EXL-650
• +GF+ Half Unions can connect to:
  1. Metric, US, or Japanese pipe
  2. PVC, PP, PVDF, or SS
  3. Threaded or welded pipe
• EXL electrode port options are Metric or US tubing (John Guest)
• EXL concentrate port options are Metric or US tubing, or MINI Sanitary Tri-Clamp

Note: The above fitting options work with all EXL models interchangeably .
