XL-R: Industrial EDI for Power Generation, Electronics, Semiconductor, and Manufacturing

Electrodeionization Technology . There are some commonalities between all EDI products. But ElectropureTM EDI technology has some fundamental advantages and differences.

Electrodeionization (EDI)  is a continuous membrane process in which a DC electric field is used to remove ions and polar species from an aqueous stream. EDI is used with reverse osmosis (RO) to replace ion exchange resin mixed beds (MBDI), which require onsite or offsite chemical regeneration.

Electrodeionization (EDI)  uses no chemicals, and generates no hazardous waste.

XL-R Electropure EDI products can handle a range of flows from 50 l/h to 2.3 m3/hr (10 gpm), depending on the specific requirements of the customer.  These are designed for rugged industrial EDI systems, whether made from PP or PVC or Stainless Steel.

XL-R

• Feed and product ports are 1-inch female pipe thread (FNPT).
• Simple systems can be built with multiple modules in parallel.
• The -R series is an improved design with the bolt heads on the opposite face.
• Non-functional show models are available for purchase on request.

Information

• Location: San Clemente, United States

Media

Taxonomy

• Water
• Electrodeionization
• Ultra Pure Water
• Power Generation
• Semiconductors
• Consumer Electronics
