How to purify muddy water for potable use
Published on by Gerhard Kistemaker in Technology
In the Foster Home that we support in Ghana, the water from 60 m deep bore well can no longer be used for drinking due to a mud contamination. The water quality (specifications) is still good, but the mud colors the water brown and negatively impacts the taste.
The well water is pumped via a PVCpipe to 4 reservoirs (plastic containers), filtered, and then distributed to approx 100 users.
The question is what filtration/purification system can we use to best alleviate these negative effects and where should the filters be installed? Can we add something in bore well itself to get better water?
Please note that we are situated in a rural area, with limited access technical support and spare parts.
Thank you for your help.
Attached some photo of the site.
Taxonomy
- Water
- Decontamination
- Wastewater Phycoremediation
- Water Distillation
- Purification
- Decontamination
- Borehole Drilling
- Contaminant Removal
- Drilling Muds
- Water Filtration
- Water & Wastewater Operations
- Water Purification
- Public Health
30 Answers
-
Dear Mr. Kistimaker;
Thank you for your inquiry.
Aquathin manufactures a broad spectrum of unique and proprietary water purification, softening and filtration systems servicing the residential, commercial and laboratory markets.
Established in 1980 Aquathin has earned 7 Patents and now produces over 70 proprietary and trademarked devices for markets around the world. Aquathin is an E.P.A. Registered manufacturer, ISO9001:2000, ISO9001:2008 Certified and recipient of both the prestigious President's Excellence & E Star Award in Export from the U.S. Commerce Department and the Nation's Blue Chip Enterprise Award from the U.S. Chamber of Commerce. Aquathin purification, softening and filtration products are Made In USA and WQA Quality and Efficiency Gold Seal Certified. We cordially invite you to visit www.aquathin.com .
For Sales, Service and Technical Support in Ghana please contact our friends and longstanding excellent Distributor at:
AQUATHIN GHANA
Simon Seddoh Bokor, Executive ManagerLadosi Ventures // Aquathin Ghana
P.O. Box DT 2752, Adenta / Greater Accra Region / Ghana, AFRICA
T 277436679/ 243688792 E: info@aquathinghana.com / bokorseddoh@yahoo.com / ladosiventures @gmail.com / Skype bokorseddoh
They have many clients in Ghana over the past years. Please feel free to contact them directly.
Again our thanks for considering Aquathin to provide your foster family the very best in water security....and warmest regards,FOR THE BEST TASTE IN LIFE &
36 Years Pure Excellence
...into another Quarter Century re-inventing the water industry !
Think Aquathin...AquathinK !
( visit the all new www.aquathin.com )
** AN ISO9001:2000, ISO9001:2008 QMS REGISTERED / CERTIFIED COMPANY - (IMS 0192, NQA 12635) **
& 2008 PRESIDENT'S E STAR AWARD RECIPIENT ( visit www.aquathin.com/estar2008.pps )
' Alfie'
Alfred J. Lipshultz
President & CEO
-
Try pumping the water to an elevated storage tank. place the outlet a foot or so above the bottom of the tank to allow mud to settle to the bottom leaving pure water on top where the outlet is. Bottom of tank will need to be drained of mud periodically. My 2 cents.
-
The colours associated with clays and muds are finely divided colloids and fines and sometimes soluble humic and fulvic acids. These contaminants can pass through filters or rapidly block filters. The most appropriate treatment that I have is used is Coagulation > Flocculation and Clarification and then use the filter as a final barrier. For remote sites, electro-coagulation, -flocculation and lamella clarifier work well. The electrical energy for electro-coagulation being generated by solar pv or other renewable energy source. See attached file showing picture of Solar based drinking water package treatment plant incorporating all these features.
File 01-05-2016, 09 41 17.jpeg
(see also www.powerandwater.com)
-
Use Charcol filter done wth Burned wood & crush an too differents diameters of sands, all that with gravity, IF POSSIBLE PUT IN INOX PIPE UVB, LED Tube of 100 Cm 150-340 Nanometers ondes with water circulation inside for complete circulation but at beginning U(ve tomake a pond for mud first deposit then to join in anther one Yogurt for probiotic treatment an too microAlgae for Nitrates treatment. This water could be completely pure, not expansive if U're a little cleaver (200 Euros total) an solar electricity include for the UVB leds. With this purifiezd water U can farm too fishes and shrimps for people feeding.
If U need more infos, contact me ray.dalaiseMohummadrashid@gmail Siddiqui
-
Low Cost 'TERAFIL' Water Filter developed by CSIR-IMMT, Bhubaneswar, India
- Application :
TERAFIL is a low cost burnt red clay porous media (disc/candle), used for filtration & treatment of turbid raw water into clean drinking water for domestic/ community applications. Suspended particles, sediment, iron & many heavy metals, micro-organism, colour & bad odour etc are separated from raw water effectively during filtration, without clogging the core of the TERAFIL. It can be fixed with any container for purification of water. Quality of product water is within BIS limits, especially for turbidity, iron & micro-organisms. Cost of purification is within Rs.2/- per ton of product water, considering total cost of plant. It operates without electricity, spent water and sludge management. Average life of TERAFIL media is five years. 1 to 50,000 lit/day capacity filter/plants is available for domestic, online & community applications. - Raw Materials:
Pottery clay, sand & wood saw dust for preparation of TERAFIL media (disc/candle). - Process Features:
TERAFIL is prepared out of a mixture of sand, red clay & wood saw dust. Terafil media comprises of thin clay walls (clay membranes) and each clay wall separated by large size pores. The thin clay walls contain ultra-fine capillary openings (sub-micron in size) which bridge the pores. Raw water flows from one pore to anther through capillary openings during filtration in Terafil media, leaving behind sediments, suspended particles etc on top surface of Terafil. Terafil helps for effective filtration & treatment of raw water into clean drinking water. Terafil is fitted at the bottom of any container for filtration and treatment of raw water. - Link http://www.immt.res.in/TERAFILWaterFilter.aspx
- Application :
-
First you have to use the sedimentation Technic using settling tanks by adding coagulants and chemical agents to speed the process.
Second take the from the surface through weer channels to a sand filter for filtration and collect in a filtered water tank, than adding a small dose of chlorine for disinfection.
Third, take a sample for laboratory testing to make sure the quality is within standards.
Fourth, it should be ready for drinking.
-
Dear all please find attached my information, the Nadi filter water unit is useful to filter muddy water and make is 100% pure and free from Biological contamination, for further more check my profile and contact me if needs more info at ahdpak@gmail.com
-
Please drill another Borehole and blend the water, again the water must pump at night to the reservoir to allow settle ability to take place. You can installed extra filters according to size, as you speak the flow rate never mentioned here. Again you can use package plant to treat that colour or muddy. You also create a slow sand filtration, where water can dose with ferric chloride before flow into sedimentation tank.
-
You dont need any kind of Infrastructure if I believe one can just use a pinch of alum and leave it to stand.can be done at Individual homes and in small vessels and the same piece of alum be used in different vessels.Just let the piece be in hand for say 30 secs, whirl it around and leave it undisturbed.Hope this helps.
This is Practised regularly in rural and urban India since generations.
-
Gerhard Kistemaker the solution is very simple, organic, food grade, requires 1 hour for generating potable grade water! No need of UF / UV / RO
For further details mail to ecoclean.pune@gmail.com
view this video link
-
Normally the borewell water mud colour is due to oxidized iron content in the ground water. Please confirm whether its mud or iron. If its mud you can use a settling tank with alum or polyelectrolyte as coagulant. If its iron then aeration and sedimentation will give you good result. In both the cases you can use a pressure sand filter for better quality.
-
Use Solutek in the overhead tanks...it is a flocculent and will also get rid of any carbonaceous materials whatsoever. There are a number of filter solutions that you could then use if you wish. Perhaps you may need to add some type of safe anti-bacterial solution.
-
Use Solutek in the overhead tanks...it is a flocculent and will also get rid of any carbonaceous materials whatsoever. There are a number of filter solutions that you could then use if you wish. Perhaps you may need to add some type of safe anti-bacterial solution.
-
Hi Gerhard,
The appearance of mud seems to be a very unlikely development at a working abstraction well. Usually mud can be present at the beginning of the operation but not after what is termed the well development. Before serious money is spent on anything else than interim treatment options the cause should be identified as this might just be a transient problem, due for instance to well pipe corrosion and wall collapse. In my experience the presence of iron might lead to well clogging and a slight colouring and or turbidity of the water but that is not mud.
If you have data 'll be happy to assist. Below some questions:
- Does the mud settle?
- For how long has the problem been going on? How much water has been pumped since the onset? Is the problem worsening, constant or getting better?
- Can a well depth measurement be performed, even if only up to the depth at which the pump is located? (Turn off the pump!)
- Can you provide analytical data of the water before and after the change?
- Do you have pictures of the muddy water?
- Can you provide information about the geological materials the well is hosted in? One of the good things with ground water is that often it is geologically prefiltered and most of the time there is no need for additional treatment measures.
- Do you have information about the well operation? Amount of drawdown and recovery when not pumping? How does it compare to the measurement data of question 3?
Best regards
Francisco
If you want to use my email: franegrao@gmail.com
-
As Michael Deed said,
iron ist the most probable reason for your combined mud/taste problem. If you cannot clean the well -certainly the best solution- you may help yourselves by letting run the water through several recipients, thus aerating the water and provoke an oxygen-triggered chemical reaction & sedimentation of the mud in the water. Thereafter, you can / should filter the water trough commercial / industrial filters like the twin big blue or the filters distributed by airjuice corp. (Australia); there are many standardized solutions appropriate for ± 100 consumers. The filters are easier to handle, than sand filters and might prove to be more econmic on the mid and long term.
-
I think simple inline pressure sand filter and activated carbon filter improves the color and odor (test). This filter can be simply install in delivery line at ground level. The pumped water first passes through these filter and stored in overhead tank.
-
Hi Gerhard,
There's lots of good information so far but if you are inexperienced in water treatment do be careful not to cause a secondary issue especially with the use of a coagulant.
In addition to the advice already provided, I would try and understand what has changed. I presume you were getting good mud-free water previously so can you identify what has changed? This may help in identifying a solution. In the meantime, you may want to consider reviewing the water quality inside your 4 reservoirs as the mud may be depositing and as they fill and discharge this will be exacerbating the problem. Assuming the mud settles, a relatively simple system (but it would involved an intermediate pump) would be to use one of the existing tanks as a settlement tank and just pull off the supernatant.
If you would like to explore my suggestions further please do email me at helenclaychapman@youlearnwater.com
Kind Regards Helen
-
The problem you describe is very likely to be due to iron related bacteria in the water. A soft rich orange brown residue forming on the inside of the well, pipes, pump and other equipment. The best solution is to clean the well and then maintain it in this manner. Have a look at this site and see if the pictures are the same as your well www.wellrehabilitationsolutions.com
-
Hi Gerhard, I suspect that your solution would be simple to install and maintain. What are your daily water requirements split into 3 categories: 1. Drinking requirement, 2. Water for washing/bathing and 3. Water for irrigation or farming activities?
Email me at: shawn@o3water.co.za and we can discuss options together and offline. -
Dear Grehard Kistemaker
We want to share a solution to filter dirty or contaminated water, a cheap and innovative solution once villagers will install than use life time at their household level. A Video showing the Nadi filter unit functioning https://www.youtube.com/watch?v=TBvclfeW_NA
we can be help at any time just send us email we will be happy to share or give training etc
-
Biosand filter might be the solution in such a situation with sedimentation prior to filteration.
enclosed is a brief note see short video also at https://www.youtube.com/watch?v=gVTrHzzxpYU
-
Gerhard Kistemaker
We do attach a nano clay candle for filtration, there are larger community level tanks fitted with our clay candles and there is provision for sludge removal using a vent valve. Basically 2 tanks one above the other, forms the filtration system and the clay candles are fitted in-between, at the bottom portion of the top tank. Water gets filtered and percolates through the candle thereby removing pathogens and colloidal materials, heavy metals etc. The pictures shows tanks modified to suit Terafil filtration and the green colour one is the same type of tank designed and moulded in a tender coconut shape! For details visit watsan.in. This is electricity free, maintenance less and does not need membranes or any replacements often!
-
1. Collect water in a pond and let the mud settle.
2. Pass the water through sand and gravel filter
3. Use the activated carbon or burn the local woods to get coal and pass the water through the clean coal without ashes.
4. Before drinking water, use the chlorine based purifier at least 30 minutes before intake.
It is short-term solution, for long-term solution, get your well checked and block the mud-section with some casing, it should help.
-
SaferEx - Water Purifier , a multi-action safe liquid that purifies contaminated borehole/well groundwater, makes it safe for drinking, hygiene and sanitation uses by killing pathogens, sedimenting particles, heavy metal ions and salts, removes odour and colour, "on single application", by simply mixing it with the unsafe water and decanting/filtering after 1-6 hours (depending on contamination type/extent) at less time and cost with efficiency compared with combinations of other treatments without desired results. It brings the pH of highly acidic and alkaline water towards/close pH7. It forms a cloudy solution with certain impure water (sediments impurities)and clear solution with pure water (without sediments), therefore can be used to preliminary detect safe and certain unsafe water instantly. It is formulated from regular and refined water treatment chemicals.
Addition of SaferEx water purifier in the overhead tanks at 5ml/20 litres water, allowing 1-6 hours and wasting the bottom sediment before passing the water through a composite filter bed or 3 micron (5, 1, 0.5 or less micron) filters in series will make the water potable.
Alternatively, the well can be compressed and flushed to reduce the mud content. Then a coagulant/clarifier can be dropped into the well. Then a measured disinfectant dosed into it in mixing before filtering and distribution.
-
A basic sand filter in the system will go a long way to solving your problems. We would suggest that the addition of our 100% fully organic product to the water before it enters the filters would keep the filters healthy and give you quite clean water. Our product needs about 72 hours residency time in a tank of water to be really effective.
Solutek is extremely low tech.....just tip it in with a cup of put a small pump into the system.
See our web site: www.soleco-technology.com
-
My instinct would be filter the water through sand protected by a porous ceramic, bound sandstone (perhaps held with a bentonite clay) or cementitious layer than can be maintained and cleaned. Water will gradually be absorbed and make its way through the porous ceramic, stone or slab and the sand (the clay will remain on the surface). It can then be run off into suitable storage containers/ ponds. If quality/taste is still an issue then you will need to consider running the water through activated carbon (as already suggested) after it passes through the sand. A simple, low cost and easy technique to try out. Worth a try.
-
You can use a sand filter or multimedia filter to remove turbidity from the source water. But the filter media will quickly foul if the water is very muddy. The best thing to do is eliminate the problem at the source. You may be able to rehabilitate the well. A good well driller could give you a better idea what you could do. Perhaps pumping the well for a long period woul clear it up. Maybe the well needs to be drilled deeper and then sealed off with bentonite. Maybe a new well is needed. Running a camera down the well may provide more details of the well failure. For the camera to be of any use the well would have to be left idle so the water column could settle and be clear enough to see through.
-
Do you have access to coconut husks and or activated carbon? You could try making a coconut fiber and charcoal filter.
http://www.all4naturalhealth.com/make-your-own-water-filter.html
I have used a hydrocyclone with great success in removing fine particulate material from my well water in North Carolina. I use one like this: https://www.google.com/?gws_rd=ssl#num=100&tbm=shop&q=irrigation+hydrocyclone+separator
You have a problem with suspended solids though probably and that silt is colloidal in nature and super small. Some type of coagulant (alum) and flocculant (acrylamide) could be used but I'm sure you don't have access to those on a regular basis for re-supply.
http://www.flocculants.info/polymer-definitions.html
-
Construct a settling tank where suspended solids will settle down and clear water can be taken from the top. A floculant may be added to speed up the settlement.
-
You have a water quality report an chemical composition of water or mud ?
